Technical Specifications
  • Size : 63mm
  • Material of Construction : Seamless Steel Tubes
  • Comforming Specification : IS 8442
  • Performance Test : (A). Hydrostatic Test (Body Test) : Tested at 21 Kgf/cm2
    (B). Discharge at working pressure 7 Kgf/cm2 : 1750LPM
  • Range: Vertical -21mtr.& Horizontal-53mtr.
  • Rotation :(A). Vertical : 125° min. (80° Upward and 45°downward)
    (B). Horizontal : 360° in either direction
